Automatic line for bread

Product Videos



Automatic line for bread

1. Dough dividers MAGNAT
  • divides the dough with big precision in wide weight range
  • has got stepless regulation of efficiency (quantity of portions/ hour)
  • is solid, simple, silent machine with unique mechanisms construction
  • dividing equipment is prepared from special durable materials
  • construction permits for easy and fast cleaning
  • fixed wheels permit for easy machine relocation
ModelDividing range[g]Portion/hour[pcs/h]Net weight: [kg]Power[kW]
Uno 175 250-1400
400-1600		 1600 450 1,2
Uno 230 500-2100
300-1600		 1600 450 1,2
Duo 175 60-650
(200-1400)		 3200
(1600)		 450 1,4
Duo 230 150-800
(500-2100)		 3200
(1600)		 450 1,4

2a. Conical dough rounder ALFA
  • Long rounder way 3600 mm (ZS 360) or 6000 mm (ZS 600)
  • Regulated weight range (moving troughs) of the rations of the dough (from 60 till 1500g)
  • Hot air injection
  • Tefloned troughs and conical
  • It is possible to install the washers, which make possible to round the dough prepared in 50% from rye flour.
  • It is possible to regulate the conical rotation
  • Strong industrial construction
ModelEfficiency[L/h]Dimensions(cm)Weight range[g]Weight[kg]Power[kW]
Alfar 400 ~2000 100x115x150 50 - 2000 320 1,5 230/400
Alfa 650 ~2500 100x115x170 150- 1200 400 1,5 230/400

2b. Belt rounder BETA
  • It is possible to round the dough rations of weight from 250 grams till 1600 grams
  • Two options of belt length 1500 and 2000 mm
  • Regulated rounding speed
  • Ensures correctness of rounding the dough prepared in 90% from rye flour
  • Unique construction - the engines were placed in going barrels
ModelLenght of belts[mm]Efficiency[L/h]Dimensions(cm)Power[kW]Weight[kg]
ZT 150 1500 1200 180 x 70 x 95 0,72 120
ZT 200 2000 3000 230 x 70 x 95 1,00 160

3. Preliminary proving rooms RELAX
ModelQuantity of basketsQuantity of portionsQuantity of rowsDimensions AxBxCQuantity of portions/h (10min proving)Quantity of portions/h (15min proving)Quantity of portions/h (30min proving)
KWR 240 240 197 8 2000x1550x2050 1100 750 400
KWR 336 336 299 8 2000x1550x2450 1750 1150 550

4. Dough longmoulder DELTA
  • Available with 1 or 2 pressure plates and width of the belt 500 mm or 600 mm.
  • Modern and quiet drive of the rolling rollers with help of the rubber belts
  • Independent drive of the belt conveyor flight and rolling rollers
  • Easy regulation of the pressure plates lifting
  • It is possible to regulate the speed of conveyor
  • Lateral regulation the length of the dough
ModelWeight range[g]Efficiency[L/h]Dimensions(cm)Power[kW]Weight[kg]
WW 600 2900 x 600 ~2000 80x230x145 1,5 450

Do you need more information?

Contact us!
